The numerical data, formulas and other calculations provided in this document are believed to be accurate and concise as of the date of printing. However, normal dimensional tolerances in actual cable constructions and variations in the installation conditions may lead to differences in the indicated values and actual measured values.
INTERCONNECT CABLES* (nanotubes conductors)
soon... |
|||
Capacitance |
33.2 pF/m at 10Khz |
39.5 pF/m at 10Khz |
39.5 pF/m at 10Khz |
Capacitance |
64.1 pF/m at 10Khz |
68.2 pF/m at 10Khz |
68.2 pF/m at 10Khz |
Dissipation factor |
0.0312 |
0.1445 |
0.1445 |
Inductance |
0.89 uH/m at 1Khz |
1.68 uH/m at 1Khz |
1.68 uH/m at 1Khz |
Resistance |
0.0593 Ohm/m20°C |
0.0812 Ohm/m20°C |
0.0812 Ohm/m20°C |
Conductors |
1x Copper 99.999% |
|
2x Silver 99.999% |
Geometry |
Nanotubes enhaced core |
sToa 8 evolution & self-shielded technologies |
sToa 8 evolution & self-shielded technologies |
Insulation |
Nanotubes treated PVC tube |
Nanotubes treated PTFE tube |
Nanotubes treated PTFE tube |
Screen |
Nanotubes treated tinned |
Triple amorphous carbon & carbon nanotubes shield |
Triple amorphous carbon & carbon nanotubes shield |
Jacket |
Double polyethylene |
Nanotubes treatet |
Nanotubes treatet |
Connectors |
Nanotubes shielded pure |
Nanotubes shielded |
Nanotubes shielded |
Colour |
White or Black |
Black-highly reflective white |
Black-highly reflective white |
External diameter |
5.2 mm |
10.8 mm |
10.8 mm |
Total weight |
71 gram/m |
78 gram/m |
78 gram/m |
Lengths available |
0.8, 1.0, 1.3, 1.5 meters** |
0.8, 1.0, 1.3, 1.5 meters** |
0.8, 1.0, 1.3, 1.5 meters** |
Warrandy |
4 years |
4 years |
4 years |
Remarks |
Hygroscopic nanotube cooling |
sToa 8 evolution technology, patented Natural Flow Cooling System, patented Elastic hanging mechanism, patented airproof mode, heavy shielded, Galvanic Isolated Shield System, |
sToa 8 evolution technology, patented Natural Flow Cooling System, patented Elastic hanging mechanism, patented airproof mode, heavy shielded, Galvanic Isolated Shield System, |
INTERCONNECT CABLES* (silver conductors)
Capacitance |
19.1 pF/m at 10Khz |
22.1 pF/m at 10Khz |
24.3 pF/m at 10Khz |
18.7 pF/m at 10Khz |
Capacitance |
24.1 pF/m at 10Khz |
28.1 pF/m at 10Khz |
61.9 pF/m at 10Khz |
39.2 pF/m at 10Khz |
Inductance |
1.22 uH/m at 1Khz |
1.33 uH/m at 1Khz |
1.23 uH/m at 1Khz |
1.89 uH/m at 1Khz |
Resistance |
0.3205 Ohm/m20°C |
0.1809 Ohm/m20°C |
0.1809 Ohm/m20°C |
0.1241 Ohm/m20°C |
Conductors |
2x Silver 99.999 % |
2x Silver 99.999 % |
2x Silver 99.999 % |
2x Silver 99.999 % |
Geometry |
self-shielded technology |
self-shielded technology |
sToa 8 |
sToa 8 evolution technology |
Insulation |
PTFE tube |
PTFE tube |
PTFE tube |
treated PTFE tube |
Screen |
No |
No |
Amorphous |
metallized braided mylar sleeves |
Jacket |
PVC - polyethylene |
PVC - polyethylene |
PVC - polyethylene |
PVC - polyethylene |
Connectors |
Gold plated RCA |
Gold plated RCA |
Gold plated RCA |
Gold plated RCA |
Colour |
Purple |
Bright-Green or Warm Yellow |
Blue-azure |
Black-gold |
External diameter |
5.2 mm |
5.2 mm |
6.3 mm |
7.2 mm |
Total weight |
20 gram/m |
21 gram/m |
30 gram/m |
38 gram/m |
Lengths available |
0.8, 1.0, 1.3, 1.5 meters** |
0.8, 1.0, 1.3, 1.5 meters** |
0.8, 1.0, 1.3, 1.5 meters** |
0.8, 1.0, 1.3, 1.5 meters** |
Warrandy |
6 years |
6 years |
6 years |
6 years |
Remarks |
Asymmetrical self-shielded geometry, patented Natural Flow Cooling System, factory mounted low capacitance connectors, lead-free and halogen-free silver soldering, halogen free jacket, patented Elastic hanging mechanism, airproofed, remarkably low weight, unique serial number, luxury real wooden box, demagnetized. |
Asymmetrical self-shielded geometry, patented Natural Flow Cooling System, factory mounted low capacitance connectors, lead-free and halogen-free silver soldering, halogen free jacket, patented Elastic hanging mechanism, airproofed, remarkably low weight, unique serial number, luxury real wooden box, demagnetized. |
sToa 8 technology, Amorphous shield, patented Natural Flow Cooling System, factory mounted low capacitance connectors, lead-free and halogen-free silver soldering, halogen free jacket, patented Elastic hanging mechanism, aiproofed, low weight, unique serial number, luxury real wooden box, demagnetized. |
sToa 8 evolution technology, |
INTERCONNECT CABLES* (copper conductors)
Capacitance (Core to core) |
69.2 pF/m at 10Khz |
144.5 pF/m at 10Khz |
164.5 pF/m at 10Khz |
Capacitance (Total cable) |
81.6 pF/m at 10Khz |
149.2 pF/m at 10Khz |
187.4 pF/m at 10Khz |
Inductance |
1.02 uH/m at 1Khz |
1.08 uH/m at 1Khz |
0.69 uH/m at 1Khz |
Resistance |
0.064 Ohm/m at 20°C |
0.067 Ohm/m at 20°C |
0.0605 Ohm/m at 20°C |
Conductors |
2 x Copper 99.99 % |
2 x Copper 99.99 % |
3 x Copper 99.99 % |
Geometry |
self-shielded technology |
External twisted |
External twisted |
Insulation |
Thin lacquer coating |
Thin lacquer coating |
Thin lacquer coating |
Screen |
No (self-shielded) |
No |
No |
Jacket |
PVC - polyethylene |
No |
No |
Connectors |
Gold plated RCA |
Gold plated RCA |
Gold plated XLR |
Colour |
Bright-Red |
Warm-gold |
Warm-gold |
External diameter |
5.2 mm |
1.26 mm |
1.30 mm |
Total weight |
22 gram/m |
11 gram/m |
58 gram (1.00m) |
Lengths available |
0.8, 1.0, 1.3, 1.5 meters** |
0.8, 1.0, 1.3, 1.5 meters** |
0.8, 1.0, 1.3, 1.5 meters** |
Warrandy |
6 years |
6 years |
6 years |
Remarks |
asymmetrical self-shielded geometry, very thin coating dielectric, factory mounted low capacitance connectors, lead-free and halogen-free silver soldering, halogen free jacket, patented Elastic hanging mechanism, airproofed, remarkably low weight, unique serial number, demagnetized. |
Very thin coating dielectric material, similar field geometry per length unit, factory mounted low capacitance connectors, lead-free and halogen-free silver soldering, remarkably low weight, carefully packed, demagnetized. |
Very thin coating dielectric material, similar field geometry per length unit, factory mounted gold plated XLR connectors, lead-free and halogen-free silver soldering, remarkably low weight, carefully packed, demagnetized. |
BALANCED INTERCONNECT CABLES*
Capacitance
|
164.5 pF/m at 10Khz |
13.1 pF/m at 10Khz |
15.2 pF/m at 10Khz |
49.5 pF/m at 10Khz |
Capacitance
|
187.4 pF/m at 10Khz |
17.8 pF/m at 10Khz |
21.6 pF/m at 10Khz |
85.4 pF/m at 10Khz |
Inductance |
0.69 uH/m at 1Khz |
1.51 uH/m at 1Khz |
1.34 uH/m at 1Khz |
1.88 uH/m at 1Khz |
Resistance |
0.0605 Ohm/m 20°C |
0.5984 Ohm/m 20°C |
0.1997 Ohm/m 20°C |
0.1292 Ohm/m 20°C |
Conductors |
3 x Copper 99.99 % |
3 x Silver 99.999 % |
3 x Silver 99.999 % |
3 x Silver 99.999 % |
Geometry |
External twisted |
self-shielded technology |
sToa 8 evolution |
sToa 8 evolution |
Insulation |
Thin lacquer coating |
PTFE tube |
treated PTFE tube |
nanotubes treated |
Screen |
No |
No |
metallized braided |
Triple amorphous |
Jacket |
No |
PVC - polyethylene |
PVC - polyethylene |
nanotubes treatet |
Connectors |
Gold plated XLR |
Gold plated XLR |
Gold plated XLR |
Gold plated XLR |
Colour |
Warm-gold |
Red-blue |
Black-gold |
Black-highly |
External diameter |
1.30 mm |
6.5 mm |
7.2 mm |
8.3 mm |
Total weight |
58 gram (1.00m) |
60 gram (1.00m) |
72 gram (1.00m) |
112 gram (1.00m) |
Lengths available |
0.8, 1.0, 1.3, 1.5 meters** |
0.8, 1.0, 1.3, 1.5 |
0.8, 1.0, 1.3, 1.5 meters** |
0.8, 1.0, 1.3, 1.5 meters** |
Warrandy |
6 years |
6 years |
6 years |
4 years |
Remarks |
Very thin coating dielectric material, similar field geometry per length unit, factory mounted gold plated XLR connectors, lead-free and halogen-free silver soldering, remarkably low weight, carefully packed, demagnetized. |
Asymmetrical self-shielded geometry, low capacitance geometry, patented Elastic hanging mechanism, factory mounted gold plated XLR connectors, lead-free and halogen-free silver soldering, halogen free jacket, remarkably low weight, unique serial number, luxury real wooden box, demagnetized. |
sToa 8 evolution technology, shielded, factory mounted gold plated XLR connectors, lead-free and halogen-free silver soldering, halogen free jacket, patented Elastic hanging mechanism, low weight, unique serial number, luxury real wooden box, demagnetized, 30-day trial period. |
sToa 8 evolution technology, shielded, Galvanic Isolated Shield System, |
* The right to change specifications without notice is reserved by the Manufacturer.
** Any other length can be custom made on your demand.
Six year warranty against manufacturing defect
Warranty is available on registered products only
________________________________________
SPEAKER CABLES* (silver conductors)
Inductance |
1.55 uH/m at 1 Khz |
1.44 uH/m at 1Khz |
1.44 uH/m at 1Khz |
Resistance |
0.0491 Ohm/m at 20°C |
0.0211 Ohm/m at 20°C |
0.0211 Ohm/m at 20°C |
Capacitance |
11.2 pF/m at 10Khz |
11.2 pF/m at 10Khz |
19.2 pF/m at 10Khz |
Conductors |
2 x Silver 99.999 % |
2 x Silver 99.999 % |
2 x Silver 99.999 % |
Geometry |
concrete analogy geometry |
concrete analogy geometry |
concrete analogy |
Insulation |
PTFE tube |
PTFE tube |
treated PTFE tube |
Screen |
No |
No |
metallized braided |
Jacket |
PVC - polyethylene |
PVC - polyethylene |
PVC - polyethylene |
Connectors |
Gold plated banana |
Gold plated banana |
Gold plated banana |
Colour |
Warm yellow or Purple |
Blue |
Black-gold |
External diameter |
5.2 mm |
6.3 mm |
7.2 mm |
Total weight |
26 gram/m |
35 gram/m |
41 gram/m |
Lengths available |
1.3, 2.0, 2.5 meters** |
1.3, 2.0, 2.5 meters** |
1.3, 2.0, 2.5 meters** |
Warrandy |
6 years |
6 years |
6 years |
Remarks |
Concrete analogy geometry, patented Natural Flow Cooling System, airproofed, factory mounted gold pleaded connectors, lead-free and halogen-free silver soldering, halogen free jacket, low weight, unique serial number, luxury real wooden box, demagnetized. |
Concrete analogy geometry, patented Natural Flow Cooling System, airproofed, factory mounted gold pleaded connectors, lead-free and halogen-free silver soldering, halogen free jacket, low weight, unique serial number, luxury real wooden box, demagnetized. |
Concrete analogy geometry, patented Natural Flow Cooling System, airproofed, factory mounted gold pleaded connectors, lead-free and halogen-free silver soldering, halogen free jacket, low weight, unique serial number, luxury real wooden box, demagnetized, shielded, sToa 8 evolution technology, patented airproof mode |
SPEAKER CABLES* (copper conductors)
Inductance |
0.68 uH/m at 1 Khz |
0.65 uH/m at 1 Khz |
1.31 uH/m at 1 Khz |
Resistance |
0.0205 Ohm/m at 20°C |
0.0104 Ohm/m at 20°C |
0.0457 Ohm/m at 20°C |
Capacitance |
117.6 pF/m at 10Khz |
153.7 pF/m at 10Khz |
17.6 pF/m at 10Khz |
Conductors |
2 x Copper 99.99 % |
2 x Copper 99.99 % |
8 x Copper 99.99 % |
Geometry |
External twisted |
External twisted |
Para//el 4 geometry |
Insulation |
Thin lacquer coating |
Thin lacquer coating |
Thin lacquer coating |
Jacket |
No |
No |
PVC - polyethylene |
Connectors |
Gold plated banana |
Gold plated banana |
Gold plated banana |
Colour |
Warm caramel glossy |
Warm caramel glossy |
Bright-Orange |
External diameter |
2.19 mm |
3.12 mm |
5.2 mm |
Total weight |
32 gram/m |
50 gram/m |
56 gram/m |
Lengths available |
1.3, 2.0, 2.5 meters** |
1.3, 2.0, 2.5 meters** |
1.3, 2.0, 2.5 meters** |
Warrandy |
6 years |
6 years |
6 years |
Remarks |
Very thin coating dielectric material, similar field geometry per length unit, factory mounted gold pleaded connectors, lead-free and halogen-free silver soldering, very low weight, carefully packed, demagnetized. |
Very thin coating dielectric material, similar field geometry per length unit, factory mounted gold pleaded connectors, lead-free and halogen-free silver soldering, very low weight, carefully packed, demagnetized. |
Para\\el 4 geometry, patented Cables airproof mode, factory mounted gold pleated copper 6N connectors, lead-free and halogen-free silver soldering, halogen free jacket, low weight, unique serial number, demagnetized. |
* The right to change specifications without notice is reserved by the Manufacturer.
** Any other length can be custom made on your demand.
Six year warranty against manufacturing defect
Warranty is available on registered products only
________________________________________
POWER CABLES* (copper conductors)
Inductance |
2.63 uH/1.7m at 100hz |
2.51 uH/1.7m at 100hz |
2.23 uH/1.5m at 100hz |
Resistance |
0.0382 Ohm/1.7m at 20°C |
0.0251 Ohm/1.7m at 20°C |
0.0185 Ohm/1.5m at 20°C |
Capacitance |
76.3 pF/1.7m at 100hz |
56.76 pF/1.7m at 100hz |
74.26 pF/1.5m at 100hz |
Power Rating |
16Amp/230volts/3.5KW |
22Amp/230volts/5KW |
28Amp/230volts/5KW |
Conductors |
3 x Copper 99.99 % |
3 x Copper 99.99 % |
6 x carbon nanotubes treated copper 99.999% |
Geometry |
External twisted |
External twisted |
External twisted |
Insulation |
Double layer |
Double layer |
PVC |
Screen |
Seperate Tinned |
Seperate Tinned |
Seperate Tinned |
Jacket |
PVC - polyethylene |
PVC - polyethylene |
PVC - polyethylene |
Connectors |
Gold plated |
Gold plated |
Platinum plated |
Colour |
Coral-Red |
Black-Silver |
Black-Silver |
External diameter |
5.7 mm |
5.7 mm |
7.8 mm |
Total weight |
380 gram/1.7m |
391 gram/1.7m |
500 gram/1.5m |
Lengths available |
1.7 meters** |
1.7 meters** |
1.5 meters** |
Warrandy |
4 years |
4 years |
4 years |
Remarks |
Up to 16 Amperes/230 volts, heavy double layer lacquer coating, high frequency noise filter, complete separate shielded conductors, factory mounted gold pleated connectors, patented Natural Flow Cooling System, halogen free jacket, demagnetized. |
Up to 22 Amperes/230 volts, heavy double layer lacquer coating, high frequency noise filter, complete separate shielded conductors, factory mounted gold pleated connectors, patented Natural Flow Cooling System, halogen free jacket, demagnetized. |
Up to 28 Amperes/230 volts, 46 layers nanotubes coating, high frequency nanotubes noise filter, complete separate shielded conductors, factory mounted platinum pleated connectors, patented Natural Flow Cooling System, halogen free jacket, demagnetized. |
* The right to change specifications without notice is reserved by the Manufacturer.
** Any other length over 1.7m can be custom made on your demand.
Four year warranty against manufacturing defect
Sub-Menu:
